Consew 357R-2 Double Needle Post Bed Drop Feed Industrial Sewing Machine with Table and Servo Motor
Complete Package: Machine Comes Fully Assembled with Table, Stand, and Servo Motor
Vertical Axis Hooks, Roller Presser Foot, Reverse Feed, Safety Clutch, Offset Needles – Narrow Gauges Only
STANDARD NEEDLE GAUGE (SPACING BETWEEN NEEDLES): 1/16" WITH ROLLER PRESSER FOOT
MACHINE APPLICATIONS:
- For sewing light to medium weight fabrics, leather, canvas, vinyl, synthetics and various coated and laminated materials
- Suitable for stitching hollow, tubular and curved articles
- For stitching ornamental and functional two needle seams
- Designed for stitching such products as wearing apparel, shoes, boots, raincoats, foundation garments, luggage, handbags, travelware accessories, leather goods, etc.
- Also used for attaching vamps and backstraps or inserting counters on heavy shoes
MACHINE FEATURES:
- Vertical axis hooks
- Drop feed
- Safety clutch mechanism prevents the hooks from being damaged
- Reverse feed for back stitching, tacking and seam reinforcing
- Roller presser foot allows turning of sharp corners and tight curves
- Flat presser foot available
MACHINE SPECIFICATIONS:
- Number of Needles: 2 (Double)
- Feeding Mechanism: Drop Feed
- Workspace: Standard Workspace
- Standard or Full Function: Standard Functions
- Speed, Max (S.P.M.): 3000
- Clearance Under Presser Foot: 15/64" (6mm)
- Stitch Length: 5 s.p.i. (5mm)
- Work Space: 1 7/8" x 3 1/2" (48mm x 85mm)
- Needle: With Roller Presser Foot DPXF22 or 134S. With Flat Presser Foot 135 x 7.
- Bobbin: Metal 10656 Pre-wound G
- Bed Size: 7" x 20 3/8" (177mm x 518mm)
- Stitch Type: 301
- Needle Bar Stroke: 1 1/4" (32mm)
- Hook" 12530
- Post Height: 7" (178mm)
- Needle Gauges Available: With Roller Presser Foot 3/6" - 3/32" (1.2mm-2.4mm). With Flat Presser Foot 1/16" - 1/2" (1.5mm - 12.7mm)
- Stitches per minute – 3000*
THE ADVANTAGES OF A SERVO MOTOR:
- Silent and use up to 90% less power than clutch motors
- 1/3 lighter than clutch motors
- With a flick of the switch you can reverse motor rotation
- No parts to wear out or adjust
- Lightweight, precise, and reliable
Thanks to the speed control feature, most users find the machine easier to use. Both beginner and advanced sewers find this feature helpful when stitching projects that require high-speed and precise stitching.
